404D-22 404D-22T Piston And Ring 115017581 For Perkins Engine

404D-22 404D-22T Piston Set (Pin w Clip) 115017581 For Perkins Engine Part

application:

Product Installation Instructions

To ensure proper installation of the 404D-22 and 404D-22T Piston Set (Pin w Clip) 115017581 for Perkins Engine Part, please follow the guidelines below:

1. Preparation: Gather all necessary tools and equipment before beginning the installation process. Ensure a clean and well-lit work area.

2. Safety: Prioritize safety measures by wearing appropriate personal protective equipment (PPE), such as gloves and safety glasses.

3. Engine Shutdown: Turn off the engine and allow it to cool down completely before starting the installation process.

4. Component Removal: Carefully remove any existing pistons, pins, and clips from the engine. Take note of their positions and orientation for reference during reassembly.

5. Inspection: Thoroughly inspect the cylinder bores, piston rings, and connecting rods for any signs of damage or wear. Replace any worn or damaged components as necessary.

6. Piston Preparation: Ensure the new piston set is compatible with your Perkins engine model (404D-22T or 404D-22TA). Clean the new piston, pin, and clip to remove any dirt or debris.

7. Lubrication: Apply a thin layer of engine oil to the piston skirt, piston rings, and cylinder bores. This will help with smooth installation and reduce friction during operation.

8. Piston Installation: Carefully insert the piston into the cylinder bore, making sure the arrow or notch on the piston crown aligns with the corresponding mark on the connecting rod. Gently tap the piston into place using a soft-faced mallet or a piston ring compressor tool.

9. Pin and Clip Installation: Insert the piston pin through the piston bosses, ensuring it is fully seated. Attach the piston clip to the groove on the piston pin, making sure it securely locks into place.

10. Reassembly: Repeat the above steps for each piston in the engine. Double-check the orientation and positioning of all components to ensure correct assembly.

11. Final Checks: Rotate the crankshaft by hand to ensure smooth movement of all pistons. Verify that there are no unusual noises or binding. If any issues are detected, retrace the installation steps and make necessary adjustments.

12. Test Run: Start the engine and let it idle for a few minutes, checking for any abnormalities in piston movement or engine performance. Monitor for leaks, unusual vibrations, or excessive smoke.

Note:

Send more information like model number, serial number, engine number, pictures size.

We will confirm much quicker(the nameplate on the assy will help a lot)

lf you don’t have an engine serial number, send us the pictures in different views of your old parts. please attache it .

YEMParts: Your Trusted Source for Quality Aftermarket Parts

YEMParts is a leading provider of aftermarket parts for a wide range of machinery, including generators, construction equipment, Excavators,Loaders,Bulldozerstrucks, and marine engines. Since our establishment in 2001, we have been dedicated to supplying high-quality parts at competitive prices, while delivering exceptional service to our customers worldwide.

Extensive Inventory

At YEMParts, we take pride in our vast inventory of over 30,000 aftermarket parts, ensuring that we have the components you need to keep your machinery running smoothly. we can promptly fulfill your order and minimize equipment downtime.

Our Commitment to Customer Satisfaction

At YEMParts, we are dedicated to solving your machinery parts needs efficiently and effectively. Here's what sets us apart:

1. Problem Solving: We understand that identifying the right parts without part numbers can be challenging. Our knowledgeable team is always available to assist you in finding the right components for your machinery. Don't hesitate to reach out to us for personalized support.

2. Worldwide Fast Shipping: Thanks to our extensive inventory and streamlined online service, we can swiftly process your order and ship your products to any location around the globe. Expect rapid and reliable delivery of your parts.

3. Quality Warranty: We prioritize the supremacy of quality in all our products. Therefore, all aftermarket parts purchased from YEMParts are backed by a warranty ranging from 6 to 12 months. Additionally, we accept returns or exchanges within 30 days of receiving your products, ensuring your satisfaction.

4. With a team of over 150 professionals and a factory spanning 20,000 square meters equipped with advanced production equipment, we guarantee the highest standards of quality. Our factory produces a wide range of engine spare parts, including pistons, rings, liners, bearing sets, full gasket kits, valve kits, crankshafts, camshafts, connecting rods, injectors, cylinder heads, cylinder blocks, water pumps, oil pumps, fuel injection pumps, starter motors, alternators, and turbochargers. We offer both aftermarket and genuine parts to meet your specific requirements, with most parts readily available in stock for prompt delivery.
